型號 Type | 最大洗滌量 Max.washing capacity (kg) | 轉筒尺寸(內徑x長度) Drum dimensions (mm) | 轉速 Speed (r/min) | 功率 Power | 蒸汽壓力 Steam pressure (Mpa) | 耗汽量 Steam consumption (kg) | 外形尺寸(長x寬x髙) Overall dimensions (mm) | 整機重量 Whole weight (kg) |
XGP-15 | 15kg | φ 520x620 | 46 | 0.75 | 0.3-0.6 | 15kg | 1100x1100x1000 | 220 |
XGP-20 | 20kg | φ 550x660 | 46 | 0.75 | 0.3-0.6 | 15kg | 1170x1100x1080 | 290 |
XGP-30 | 30kg | φ 660x800 | 36 | 1.1 | 0.3-0.6 | 18kg | 1500x1190x1180 | 400 |
XGP-50 | 50kg | φ800x980 | 36 | 1.5 | 0.3-0.6 | 20kg | 1700x1320x1350 | 500 |
XGP-70 | 70kg | φ950x1220 | 34 | 2.2 | 0.3-0.6 | 30kg | 1980x1530x1520 | 700 |
XGP-100 | 100kg | φ960x1420 | 34 | 3 | 0.3-0.6 | 45kg | 2200x1400x1590 | 960 |
XGP-150 | 150kg | φ 1060x1650 | 33 | 4 | 0.3-0.6 | 50kg | 2480x1550x1700 | 1150 |
XGP-200 | 200kg | φ1080x2000 | 32 | 5.5 | 0.3-0.6 | 60kg | 2950x1700x1750 | 1500 |
XGP-250 | 250kg | φ1200x2280 | 30 | 7.5 | 0.3-0.6 | 70kg | 3200x1800x2200 | 1950 |
XGP-300 | 300kg | φ1300x2280 | 28 | 7.5 | 0.3-0.6 | 80kg | 3200x2000x2300 | 2300 |
XGP-400 | 400kg | φ1220x3360 | 27 | 7.5 | 0.3-0.6 | 100kg | 4100x2150x2350 | 3100 |
<
<
<
<
